Biometric

OX-866

  • AI-powered facial recognition with 0.3-second detection
  • Supports Face, Password, RFID, and NFC
  • Stores up to 50,000 users and 1,000,000 transactions
  • IP68 waterproof and IK04 vandal-proof housing
  • Integrated with cloud-based time attendance and payroll software
  • Anti-spoofing technology ensures secure, real-time verification
  • Compatible with Wi-Fi, 4G, TCP/IP, RS232, RS485, and Wiegand
  • Includes mobile app, leave management, and visitor tracking
  • 8" IPS touchscreen with 2MP WDR camera and live body detection

  • Description
  • Specifications
  • Download
  • Videos
The OX-866 AI Face Recognition & Cloud-Based Access Control Terminal is a cutting-edge security and time attendance solution, integrating advanced AI facial recognition technology with cloud connectivity for flexible deployment across industrial, commercial, and environmental settings.

It supports multiple authentication methods including face recognition, password, RFID card, and NFC, with anti-spoofing capabilities to distinguish real faces from photos or videos. Its high-speed recognition system identifies faces in 0.3 seconds, handling up to 50,000 facial templates and 1 million transaction logs.

Built with a robust IP68 waterproof and IK04 vandal-proof design, the OX-866 is well-suited for harsh indoor or outdoor conditions. It offers extensive communication options including TCP/IP, Wi-Fi, RS485, RS232, and optional 4G, ensuring seamless integration into any network.

The system includes cloud/web-based software for time attendance, payroll (including WPS reporting), access control, visitor management, and document expiry alerts—with mobile apps and notifications via email, WhatsApp, and SMS.

Its all-in-one functionality, durable build, and rich software support make it ideal for modern organizations seeking secure, scalable access control with integrated personnel management.
Attribute Value
Model OX-866
Recognition Speed 0.3 seconds
Face Capacity 20,000 (standard) / 50,000 (optional)
Transaction Capacity 1,000,000
Access Methods Face, Password, RFID, NFC
Anti-Spoofing Yes (live body detection)
Display 8" IPS Touchscreen
Camera 2MP WDR Low-Light
Connectivity TCP/IP, RS485, RS232, Wi-Fi, 4G (optional)
Protection Rating IP68, IK04
Software Cloud-based time & access management
Power Supply 12V DC, <2000mA
Operating Temp -30°C to 60°C
Dimensions 190.6 × 92 × 25 mm
Weight 683g-
File Icon OX-866 - Data Sheet File size: 2.76 MB Last updated: 06 May 2025 Download
